An AI-Based Prototype for Automating Product Monitoring

AI / ML
AWS
Docker
IoT
Java
JavaScript
Python
TensorFlow

The customer of Altoros delivered a prototype that simplifies real-time tracking of ice cream in freezers at retail stores.

An AI-Based Prototype for Automating Product Monitoring

About the project

Brief results of the collaboration:

  • With recognition precision of 95%, the customer can check its freezers—located at points of sale—more efficiently.
  • Getting notifications when a freezer is filled under the established minimum (70%), merchandisers can take immediate actions on the go.
  • The pilot version of the solution was developed in just 40 hours.
  • With the delivered prototype, the customer is on the way to developing a fully functional system to optimize its supply chain across California.

The customer

The company is one of the world’s leading food and beverage producers. Operating in 190+ countries, the goods portfolio features 2,000+ brands. Ice cream is among the most popular customer’s products with eight major labels and hundreds of flavors sold in branded freezers.

The need

The customer wanted to develop an image-recognition prototype addressing two major business needs:

  • Monitor the overall occupancy of a freezer in a retail location
  • Estimate the percentage ratio of the customer’s ice cream vs. other brands inside the freezer

The goal was to aid merchandisers in checking the state of freezers, while notifying responsible parties in case the quantity of ice cream is insufficient. Focusing on optimizing its routine retail operations, the company turned to Altoros for assistance.

The challenge

The team at Altoros had to address the following challenges:

  • Achieve high precision of product recognition and freezer occupancy
  • Maximize performance to ensure real-time data flow from a network of stores.

The solution

The system was developed using Altoros’s IoT prototyping platform, which was easily customized for the company’s needs. Its reusable components (NodeRED-based flow designer, time-series data store, and a monitoring module) allowed for quickly delivering necessary functionality. In accordance with the 12-factor approach, the prototype was designed as a microservices architecture—to introduce updates to each service independently, to utilize different languages (Java, Python, JS, etc.), and more.

To guarantee high precision of image recognition, engineers at Altoros tried out 10+ artificial intelligence models and 20+ machine learning algorithms. To better recognize which brand is depicted, our developers designed a custom algorithm that split the photo of a freezer into a number of segments—each containing an image of a single ice cream. To further classify the products into brands, data scientists at Altoros utilized the Inception v3 model. The combined approach allowed for achieving 95% of precision.

The model training—based on TensorFlow—involved a data set of 1,500 images created by Altoros specifically for the purpose.

To provision high performance of training, our engineers employed Intel’s Streaming SIMD Extensions 2 over Amazon’s c4.large instances. These extensions helped to perform operations over arrays of values—instead of single values—thus, boosting performance by 5x.

By enabling classification of ice cream images in parallel, experts at Altoros optimized the time needed to identify an exact ice cream item: from 7 minutes to 40 seconds. Our team also evaluated how incorporating TensorFlow processing units (TPU) can further accelerate performance.

To demonstrate and test the prototype operations, engineers at Altoros designed a simulator that imitated the solution’s workflow in production.

The outcome

Collaborating with Altoros, the customer implemented a successful proof-of-concept (PoC), verifying how machine learning can help to automate retail supply chain. The pilot version of the prototype was delivered in 40 hours, recognizing ice creams within a freezer with the precision rate of 95%.

Relying on the PoC, the customer is building a system that will gather information across California local stores in real time. The flexibility of the AI model enables to easily retrain it to recognize new assortment—such as new ice cream items or any other goods. It is expected to save merchandizers hours per day on checking ice cream availability.

Technology stack

Infrastructure

Amazon Web Services

Server platform

Altoros’s IoT prototyping platform

Programming languages

Python, Java, JavaScript

Technologies

TensorFlow, Jenkins CI, Docker, Node.js

Databases

AWS S3, InfluxDB, PostgreSQL, Redis

/
